IRHD Rubber Digital Hardness Tester

Product Item : RHT-830
Category： Products
Rubber Digital Hardness Tester
Rubber Hardness Tester
Hardness Tester
Product description：It is to measure the international IRHD hardness values of rubber and similar rubber materials test pieces and specimens.
INQUIRY

IRHD Digital hardness tester is to measure the international IRHD hardness values of rubber and similar rubber materials test pieces and specimens. It can measure rubber in the range of 10 to 100 IRHD.

Product Features

1. Touch screen control.
2. High precision sensing system, color large touch screen LCD display, touch control operation method.
3. Three hardness tests(L, N ,H) by changing three different indenters and test feet.
4. Hardness measurement range 10~100IRHD
5. (L, N ,H) Three methods combined in one.

Technical Data

Test	Diameter (mm)	Contact force (N)	Press-in force (N)	Total Force (N)	Force on the compression foot (N)
Method N (Neutral test)	Ball: 2.5±0.01	0.30±0.02	5.4±0.01	5.7±0.03	8.3±1.5
	Pressure Feet: 20±1
	Hole 6±1
Method H (High Hardness)	Ball 1.00±0.01	0.30±0.02	5.4±0.01	5.7±0.03	8.3±1.5
	Pressure Feet 20±1
	Hole 6±1
Method L (Low hardness)	Ball 5.00±0.01	0.30±0.02	5.4±0.01	5.7±0.03	8.3±1.5
	Pressure Feet 22±1
	Hole 10±1
