CNC Vision Measuring Machine

The vision measuring instrument is a high-precision, high-tech measuring instrument, mainly used for dimensional measurement and shape and position tolerance detection on two-dimensional planes. It sends the image of the measured object to the computer through the CCD camera system, and uses computer software for image processing and dimension calculation, so as to achieve accurate measurement of the contour and surface shape size, angle and position of various complex workpieces.

Measure geometric dimensions on a plane such as diameter, radius, length, angle, width, height, depth, point-to-point distance, point-to-line distance, center distance, etc. Part photo function for easy visual comparison. The software analyzes the measurement data at any time. The measurement data can be directly imported into Word, Excel and other software for analysis. With automatic edge finding, measurement is faster and more accurate. It can be saved in DXF format and data can be transferred seamlessly using auto CAD software. It can be edited and used directly in Auto CAD, making measurement results more convenient and faster.

Vision measuring instruments are widely used in machinery, electronics, molds, injection molding, hardware and other industries, and are important tools for precision measurement and quality control in these fields. Its emergence overcomes the shortcomings of traditional projectors, integrating optical, mechanical, electrical, and computer imaging technologies to achieve high-precision and high-efficiency measurement needs.
