Home Products Textile Testing Equipment Textile Needle Detector

Textile Needle Detector

Product Item : ND-600
Category： Textile Testing Equipment
Textile Needle Detector
Needle Detector
metal detector
Product description：Textile Needle Detector is a kind of textile testing equipment. It is used to detect the broken needles in textile, shoe nail, iron wire and other metal pieces left inside toys, garments, textile ,sho
INQUIRY

Textile Needle Detector also a kind of textile testing equipment ,is used to detect the broken needles in textile, shoe nail, iron wire and other metal pieces left inside toys, garments, textile ,shoes ,textile testing ,etc.

Textile Needle Detector Specification

Detecting method	Magnetic induction
Detecting width	600mm
Detecting height	100mm-120mm-150mm-200mm
Detecting adjustment	Stepless adjustment
Detecting ability	0.8-1.0-1.2-1.5mm iron ball
Alarm method	Buzzer
Belt speed	appr. 40m/min
Power supply	AC110-230V,50-60Hz
Rated output	100W
Dimension	1650×1050×900mm
Weight	175Kg

Textile Needle Detector Features

Japanese technique, anti-disturbance computer chip integrated circuit
High sensitivity, easy to maintain
Specially has the protection circuit, it will auto-stop if no detection goods in 10 minutes
Has the switch function for B/C (supplementary material/product), adapt to detect different products
Can keep a long time to work, the efficiency can reach 100% when properly used
When detect the broken needle, or Fe, it will alarm by sound and light, the engine will stop and return to the start point, and then move automatically again.
To adjust the sensitivity between 0-10 level, operation board is light touching-type, easy to operate
Can calculate the qualified and unqualified amount
