Plastic Pipe Thickness Tester

Product Item : ZY-TS903
Category： Products
pipe thickness tester
thickness meter
pipe thickness tester price
Product description：Plastic pipe thickness tester is suitable for high-precision thickness measurement of various materials, and can be applied to the thickness measurement of objects made of plastics, various metals (st
INQUIRY

Plastic Pipe Thickness Tester Introduction

It is suitable for high-precision thickness measurement of various materials, and can be applied to the thickness measurement of objects made of plastics, various metals (steel, stainless steel, aluminum, copper, etc.), quartz, glass, etc.

Test method: Place the probe on the contact surface on one side of the object to be measured, and the thickness of the object to be measured can be measured quickly and accurately.

Plastic Pipe Thickness Tester Technical Data

odel	ZY-TS903
Test range	Full range: 0.55-500mm
	Ultra-thin mode: 0.55-1mm
	Standard mode: 0.75-500mm (Standard probe: 5P, φ10)
Display accuracy	0.01mm
Measurement error	±（0.5%H+0.05）mm
	H is the thickness of the object being measured
Material sound velocity	1000-9999m/s
LCD screen	2.3-inch large color screen display
Calibration function	Instrument calibration and sound velocity calibration
Data storage function	Each group can store 200 data, a total of 10 groups can store 2000 data
Power level display	Yes
Shutdown method	Manual/automatic (automatic shutdown after 5 minutes of no operation)
Host dimensions	130mm70mm26mm
Power supply	Three (7) alkaline batteries
Operating temperature	0℃-50℃
Operating humidity	20%RH—90%RH
Weight	125g (excluding probe and battery)
