X Ray Fluorescence Spectrometer

Product Item : XRF-SU
Category： UV Spectrophotometer & Spectrometer
Fluorescence Spectrometer
Fluorescence Spectroscopy
XRF Spectrometer
Product description：It’s for RoHS Directive control: large household appliances, small household appliances, information technology and communication equipment, electric tools, toys and other equipment. For halogen-free
INQUIRY

Product Introduction

It specializes in RoHS instructions, halogen-free instructions, WEEE instructions, soil, ore composition analysis, copper alloy, stainless steel grade identification of high-end models. Keywords triple ray protection system; humanized operation interface; It can control the Cr of Br, hexvalent chromium in Pb,Cd,Hg,PBB and PBDE of RoHS instruction and the Cl and Br elements in halogen-free instruction, and can also identify soil, ore composition analysis, copper alloy and stainless steel grade. It can
fully meet the requirements of customer environmental control and material identification. Carefully designed open working curve function, especially suitable for Multi-material plant process control.

Application

It’s for RoHS Directive control: large household appliances, small household appliances, information technology and communication equipment, electric tools, toys and other equipment. For halogen-free instruction control: products that use flame retardants containing elements such as Cl,Br as raw materials.

Analysis and content Test of elements in Copper Alloy, Ferroalloy, Aluminum Alloy, Titanium Alloy, Superalloy and all kinds of Hybrid Alloy.

Technical Data

Instrument Size(WDH)	680* 400* 390mm
Sample Cavity Size	300 * 360 * 100mm
Test Element Range	elements in S-U
Detection Range	1ppm-99.99%
RoHS Detection Limit	Pb≤5ppm, Cd/Cr/Hg/Br≤2ppm, Cl≤50ppm
Test Sample Type	solid, powder and liquid
Measurement Time	120-400s (system automatically adjust)
The Best Resolution	see the detailed description of the detection system below
Collimator	Φ2mm, Φ5mm
Filter	8 kinds of composite filters automatically switch
CCD Observation	1.3 million pixel HD CCD
Sample Fretting Range	XY8mm
Input Power	AC220V ~ 240V, 50 / 60Hz
Rated Power	350W
Weight	About 45Kg
Working Environment Temperature	temperature 15-30 ° C
Working Environment Relative Humidity	≤ 85% (no condensation
