Lab Accelerated Aging Tester

Product Item : ZYAT-68
Category： Environmental Test Chamber
Accelerated Aging Tester
Accelerated Aging Test Chamber
Accelerated aging chamber
Product description：The high pressure accelerated aging test chamber is also known as the HAST chamber. They are mainly used to test IC sealing packages, LCD/LED screens, multi-layer PCBs, magnetic materials, semiconduct
INQUIRY

Product Introduction

The high pressure accelerated aging test chamber is also known as the HAST chamber. They are mainly used to test IC sealing packages, LCD/LED screens, multi-layer PCBs, magnetic materials, semiconductors, etc. It tests these products for their resistance to pressure and air tightness.

Technical Data

Inner box size	350*500 mm (φ D) circular test box
Size of outer box	6501520900 mm (WHD)
Temperature range	105℃~132℃.(Saturated vapor temperature)
Humidity range	100% RH.(Saturated vapor and humidity)
Pressure range (pressure on the table)	0.2 Kg / cm2 ~ 2.0 Kg / cm2 or (2.2 Kg / cm2) control point pressure (safety pressure capacity 3.5 Kg / cm 2)
Time range	0 ~ 999 hours adjustable
Temperature distribution	± 2.0℃
Pressure time	0.0 Kg / cm2 ~ 2.2 Kg / cm 2 within about 45 minutes (control point pressure)
Control object	Microcomputer + P.I.D.+S.S. The R autocalculus controls the saturated vapor temperature
Control mode	microcomputer PID control
Control accuracy	± 0.5℃
Parsing accuracy	0.1℃
