Dart Impact Testing of Polyethylene Film
- Product Item : ZHIYI-818
- Category： Paper, Packaging & Print
- Product description：Dart Impact Testing of Polyethylene Film
Specifications
|
Item |
Technical Parameters |
|
Standards |
ASTM D3420, GB/T 8809 |
|
Maximum impact energy |
3J |
|
Test precision |
0.001J |
|
Pendulum angle |
90° |
|
Pendulum swing radius |
280mm |
|
Size of impact head |
Φ12.7mm,Φ19mm,Φ25.4mm |
|
Size of clips |
Φ60mm,Φ90mm |
|
Size of test sample |
100mm × 100mm |
|
Instrument size |
480mm × 330mm × 540mm |
|
Weight |
48 kg |
|
Power supply |
AC 220V，50Hz |
|
Power |
1000W |
Features
◆ LCD display test data.
◆ Easy to operate, auto process data.
◆ Pneumatic clips.
◆ Automatically clip and release dart.
◆ Built-in printer can print report.
◆ Can change impact head and clips.
