Wool Fiber Length Measuring Machine Comb Sorters

Product Item : ZHIYI-131
Category： Textile Testing Equipment
Product description：Wool Fiber Length Measuring Machine Comb Sorters is designed to test the fiber length.
INQUIRY

Introduction

The fiber length tester is used to test the fiber length of wool.

Technical Data

Interval between 2 neighboring faller bars	10 mm
Total width of needles on bar	150 mm
Height of needle	15 mm
Retaining bars quantity	5pcs
Faller bars quantity	31pcs
Needle gauge and quantity of needle per cm. For both retaining bar and faller bar	26X14
Bar thickness	2.5 mm
Dropping down of faller bars	Controlled by spring loaded nipples
Overall dimensions (L x W x H)	390×295×292mm
