Accelerated Aging Chamber

Product Item : ZYAC-80
Category： Environmental Test Chamber
Accelerated Aging Chamber
Aging Chamber
Accelerated Aging test Chamber
Aging test Chamber
Product description：The ozone aging test chamber simulates and strengthens the ozone condition in the atmosphere, getting approximate actual use or reproduction of the test results in a short time. The study of ozone eff
INQUIRY

Product Introduction and Application

It is mainly suitable for polymer materials and products (rubber) of the resistance to ozone aging performance test. Ozone content in the atmosphere is very low, but it is the main factor of polymer materials aging. The ozone aging test chamber simulates and strengthens the ozone condition in the atmosphere, getting approximate actual use or reproduction of the test results in a short time. The study of ozone effect regulation on rubber products quickly identifies and evaluates rubber materials' resistance to ozone and antiozonant protection efficiency method, and then takes effective aging-proof measures to improve the service life of rubber products.

Product Features

1. User friendly

2. Over heating protection

3. Safety and Reliability

4. Filled with Eco-Friendly refrigeration

5. High-speed heating heater and high-temp MgO Powder which ensure response quickly and long lifespan

Technical Data

Model	ZYAC-80	ZYAC-150	ZYAC-225	ZYAC-408	ZYAC-800
Inner size WHD(cm)	405040	506050	608580	608580	80100100
Outer size WHD(cm)	8514095	95150115	95165115	105175135	145190135
Inner material	SUS 304 stainless steel
Outer material	SPCC Painted
Temperature range	RT+10°C~60°C
Temperature deviation	±0.5°C (no load)
Temperature uniformity	±2°C (no load)
Ozone concentration range	0~500pphm (or custom-made)
Ozone concentration deviation	10%
Ozone flow rate	12~16mm/s
Sample shelf rotating speed	20~25mm/s
Controller	TATO touch screen programmable controller
Ozone generator	using a voltage-silent discharge tube produces ozone
Power	AC 380V 3 phase 4 lines
