Cabinet Xenon Test Chamber to replace Q SUN

Characters

1.Three xenon lamps imported from America can offer higher irradiance energy, meet with all test standards requirements.

2.Can set and control automatically the relative humidity of working room.

3.The test procedures can be programmed freely; and up to 6 predetermined procedures can be saved in one time. Every procedure includes up to 10 segments setting data.

4.Can set the cumulative energy (total irradiance energy) obtained by sample to finish a test procedure.

5.With front spray function, can set spray time and spray interval time.

6.Irradiance energy can be accurately controlled. The "Closed-Loop" control system can automatically compensate the change of light intensity caused by ageing or other factors.

7.Users can easily calibrate and adjust the irradiance or the black panel temperature by themselves.

8.With high precision Pt100 temperature sensor. Black panel temperature is auto-controlled during the whole process.

9.Alarm function for protection: Over-temperature of BPT or BST, big irradiance difference, auto shut-down protection when opening door, spraying water shortage, big error of humidity, large deviation of working room temperature, air pressure protection of lamp cooling air.

10.Touch screen and user-friendly operation interface allow operator to set the test parameters and monitor all the test process easily.

11.Specimen mounting and evaluation is fast and easy with unique slide-out specimen tray.

12.Real-time data can be collected and recorded. The incidental USB connector allows users to copy the test data into a USB drive, achieving unattended operation.

Test Standards

ISO 12040 Graphic Technology - Prints and Printing Inks - Assessment of Light Fastness Using Filtered Xenon Arc Light

ISO 16474-2 Paints and varnishes -- Methods of exposure to laboratory light sources -- Part 2: Xenon-arc lamps

ASTM D3451 Standard Guide for Testing Coating Powders and Powder Coatings

ASTM D4303 Standard Test Methods for Lightfastness of Pigments Used in Artists' Paints

ASTM D6577 Standard Guide for Testing Industrial Protective Coatings

ASTM D6695 Standard Practice for Xenon-Arc Exposures of Paint and Related Coatings

ASTM G151 Standard Practice for Exposing Nonmetallic Materials in Accelerated Test Devices that Use Laboratory Light Sources

ASTM G155 Practice for Operating Xenon Arc Light Apparatus for Exposure of Non-Metallic Materials

ISO 4892-1 Plastics Methods of Exposure to Laboratory Light Sources Part 1: General guidance

ISO 4892-2 Plastics - Methods of Exposure to Laboratory Light Sources - Part 2: Xenon-arc lamps

SAE J2412 Accelerated Exposure of Automotive Interior Trim Components Using a Controlled Irradiance Xenon-Arc Apparatus

SAE J2527 Accelerated Exposure of Automotive Exterior Materials Using a Controlled Irradiance Xenon-Arc Apparatus
