Haze Meter Transmittance Meter For transparent film plastic and screen

Model

ZHIYI-1003

Optical path structure

D/0

Wavelength range

400-700nm

Wavelength interval

10nm

Measuring aperture

21mm , 7mm

Measurement conditions

Light source: CIE-A, CIE-C, CIE-D65 , A, C, D50, D55, D65, D75, F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12, CMF, U30, DLF, NBF, TL83, TL84

Observer angle: 2°, 10°

Measuring time

Transmittance/haze: about 3s, other chromaticity indicators: 0.6s

Measurement parameters

Haze, total transmittance (T), spectral transmittance, CIE Lab, LCh, CIE Luv, XYZ, Yxy, Hunter Lab, MunsellMI, CMYK, whiteness WI (ASTM E313-00, ASTM E313-73,CIE/ISO,Hunter,Taube Berger Stensby),Yellowness YI(ASTM D1925,AST

M E313-00, ASTM E313-73), Tint (ASTM E313-00), Metamerism Index Milm, APHA, Pt

-Co (Platinum Cobalt Index), Gardner (Gardner Index), Color difference (△E*ab, △E*CH, △E*uv, △E*cmc (2:1),

△E*cmc(1:1),△E*94,△E*00)

Transmittance resolution

0.01%

Transmittance accuracy

Better than ±1%

Transmittance repeatability

≤0.03 (without preheating, standard deviation of 30 times of measuring a standard haze sheet with a haze of about 30 at 3s intervals)

Haze resolution

0.01%

Haze accuracy

Better than ±1%

Haze repeatability

≤0.03 (without preheating, the standard deviation of 30 times of measuring the standard haze sheet with a haze of about 30 at an interval of 3s)

Chromatic aberration repeatability

Standard deviation △E*ab, within 0.03 (measurement conditions: no preheating correction required, average value of 30 measurements of white glass at 3s intervals)

Platinum-Cobalt Chroma Resolution

0.01

Platinum-Cobalt Color Range

0-500

Platinum-Cobalt Chromaticity Accuracy

≤±(5%H+1), H is the standard value

powered by

DC12V/3A

Display

7-inch touch screen, Android system

System language

14 languages

Data Interface

USB(Type-B)

Operating temperature range

5~40℃, relative humidity 80% or lower (at 35℃), no condensation

Storage temperature range

-20℃~45℃, relative humidity 80% or lower (at 35℃), no condensation

Instrument dimensions

Length*width*height: 310mm*215mm*540mm

Instrument weight

5300g
