Paperboard Thickness Gauge

Product Item : ZY-H4
Category： Paper, Packaging & Print
thickness tester
paperboard thickness tester
thickness gauge
paperboard thickness gauge
Product description：This Paper and cardboard thickness is a special apparatus to measure the thickness of paper and cardboard , widely used in paper, cardboard and other sheet materials, and it is an indispe
INQUIRY

Specifications

1. Paper and cardboard thickness guage
2. As per ISO438,534
3.Measuring range :0-6mm
4.widely used in paper, cardboard

Paper and Cardboard Thickness Gauge Introduction:

This Paper and cardboard thickness is a special apparatus to measure the thickness of paper and cardboard , widely used in paper, cardboard and other sheet materials, and it is an indispensable instrument for cardboard carton production, research and inspection.

Paper and Cardboard Thickness Gauge Technical Data

Test standards	ISO 534,ISO 3034
Measuring range	0-20mm
Accuracy	0.01mm,0.001mm
Contact pressure	100±1 kPa
Contact area	10±0.2mm2
Parallelism	≤0.005mm
Dimensions	375264400mm
Weight	About 6kg
