Sweating Thermal Test Chamber

Sweating Guarded Hotplate is the most professional, stable and advanced Thermal and Evaporative Resistance test instrument in the world.

Human skin simulation test plate, automatic water supply system, wind speed stabilization system, test host and climate chamber completely separated design. Automatically adjust the height of the hotplate according to the thickness of the test sample, ensures the wind sensor is 15mm above the hotplate.

1.2 Standards

l ISO 11092

l ASTM F 1868

l ASTM D 1518

l GB / T 11048

l JIS L1096-2010

1.4 Specifications

l RCT test range: 0.001~2.0 m2.K/W

l resolution ratio: 0.0001 m2 .K/W

l Ret test range: 1.0~1000 m2.Pa/W

l resolution ratio: 0.001 m2·Pa/W

l The temp. range of test plate: 30 ℃ ~ 40 ℃ adjustable

l The accuracy of Temp.: ±0.03℃

l The resolution of Temp.: ±0.01℃

l Air verlority: 0-1.2m/s adjustable

l The accuracy of air velority: ±1%

l The area of test plate: 254mm×254mm

l Power: AC220V±10%,100W

l Weight: 60 kg

l Dimensions: 730×610×350mm(L×W×H)
